1000-1000000 Liters Per Hour Capacity Iron And Manganese Removal Well Water Filter With Quartzite Filtration Method

Brand Name:	nettronics
Model Number:	JC-1-100T/D
MOQ:	1
Price:	liaise
Payment Terms:	T/T
Supply Ability:	liaise

Detail Information

Product Description

Detail Information

Place of Origin:

sino

Certification:

Control Method:

Automatic And Manual

Control Mode:

Flow Rate Type, Time Type

Application:

Treat Hard Water

Operating Temperature:

5-50 Degrees Celsius

Inlet Water Pressure:

0.2～0.4Mpa

Water Softening Method:

Ion Exchange

Flow Rate:

10 Gallons Per Minute

Keywords:

Water Softener

Weight:

100-10000 Kglink Up

Capacity:

1000-1000000 Liters Per Hour

Function:

Soften Water And Remove Hardness

Material:

Stainless Steel

Type:

Whole House Water Filter

Filter Size:

20 Inches

Filtration Method:

Manganese Sand, Activated Carbon, Quartzite

Maximum Pressure:

1000-100000 Psi

Warranty:

1 Year

Dimensions:

20 X 4.5 Inches

Dimensional Flow:

Communication Negotiation

Packaging Details:

Export Wooden Box

Highlight:

Iron Manganese Removal Well Water Filter

1000000 Liters Well Water Filter

Quartzite Filtration Well Water Filter

Product Description

Automatic Iron and Manganese Removal Well Water Filter

Groundwater Treatment Solution

Groundwater in many regions contains elevated levels of iron (5-15mg/L, up to 20-39mg/L) and manganese (0.5-2.0mg/L, sometimes exceeding 2.0mg/L). When iron exceeds standards, it exists as Fe2+, making water appear clear initially but turning turbid over time with a distinct ferruginous odor. This poses significant challenges for industrial applications, including resin contamination in ion exchange systems, reverse osmosis membrane fouling, boiler scaling, and accelerated equipment corrosion through iron bacteria proliferation.

Advanced Filtration Technology

Our iron and manganese removal filter integrates oxidation, ion replacement, retention, and clarification processes. The system employs aeration technology—using jet aeration or hollow multi-faceted ball aeration—to oxidize bivalent iron and manganese into Fe(OH)3 and MnO2 precipitates. Through single or multi-stage filtration, we ensure treated water meets national drinking water standards with iron content ≤0.3mg/L and manganese content ≤0.1mg/L.

Drinking Water Compliance

After treatment, groundwater iron content is reduced to ≤0.3mg/L, fully compliant with the national GB5749-85 drinking water quality standard. This makes our system ideal for towns, industrial enterprises, and mining operations using groundwater sources.

Application Scope

Groundwater iron content ≤8mg/L removal systems
Groundwater iron content >8mg/L to ≤16mg/L removal systems
Small to medium towns, rural water supply systems
Industrial and mining enterprise water treatment
Softening and desalination pretreatment processes

System Advantages

Fully automatic operation from inlet to discharge
No additional equipment required (air compressors, backwash pumps, or water towers)
High-efficiency manganese sand filter media for reliable performance
Optional electrical control system for unattended operation

Technical Specifications

Parameter	Specification
Feed Water Iron Content	≤8mg/L or >8mg/L～≤16mg/L
Effluent Iron Content	≤0.3mg/L (GB5749-85 compliant)
Surface Load	8-9 M³/H·M²
Flushing Intensity	14-16 L/S·M²
Flushing Time	4-6 minutes (adjustable)
Inlet Pressure	0.2 MPa
Filter Media	Delicate manganese sand 0.5-2mm particle size
Working Temperature	5℃～40℃ (customizable)

Multi-Media Filtration System

This advanced micro-flocculation filtration method utilizes multiple layers of specialized filtration media to remove suspended matter, particles, colloids, algae, and other visible contaminants. The system effectively reduces turbidity and chromaticity while ensuring SDI values ≤4, providing essential protection for downstream RO systems. Features include low operational costs, easy maintenance, and backwash cycles of 16-48 hours controlled by pressure parameters.

Activated Carbon Filtration

Our activated carbon filtration provides comprehensive water treatment with multiple benefits:

De-coloring: Removes chromaticity from iron, manganese, and organic pollutants
Dechlorination: Eliminates residual chlorine odors
Organic removal: Targets pesticides, insecticides, chlorinated hydrocarbons, and reduces BOD/COD
THMS removal: Effectively eliminates trihalomethanes and other disinfection byproducts
Ammonia and nitrite removal
Protection for ultrafiltration and reverse osmosis membranes

Water Softening System

The softener utilizes strong acid-type cationic resin to remove calcium and magnesium ions, reducing water hardness to <0.03meg/L (CaCO3) and preventing scale formation. The corrosion-resistant stainless steel tank (3,000L/hr capacity) features robust control valves, high-efficiency resin, and an advanced salt suction system with automatic filtration and water return functions. Ideal for boiler water treatment, solar heating systems, chemical processes, and various industrial applications.

Important Note: Due to product specificity, please contact our customer service before purchasing. Our team will analyze your water consumption and quality issues to recommend the optimal solution. Avoid unnecessary complications by consulting with our experts for specific specifications, parameters, and technical details. Thank you for your support of Net Environmental Protection.
