One of the most valued solutions for Nettronics' environmentally friendly yachts is the ability to produce fresh water. As a distinctive feature of environmentally friendly yachts, a yacht desalination machine can efficiently purify seawater into drinkable fresh water through reverse osmosis membranes, which reduces the amount of bottled drinking water in reserve. A desalination machine not only minimises plastic waste, but also enhances self-sufficiencyBusiness Boat Desalination Machines - Nettronics

Drinking water is the source of life, at present the world's population of 2 billion people face a lack of fresh water resources, which water scarcity is concentrated in some island countries, saline and alkaline areas, including ocean-going ships, offshore drilling platforms, etc., desalination units focus on solving the problem of drinking water on ships, islands, drilling platforms, saline and alkaline areas, etc., desalination of seawater to solve the problem of drinking water.

Product Parameters of Nettronics Desalination System:

Product Model: JC-2T/D

Water quality: Comply with drinking water quality standard GB5749-2022

Water production :250 litres/hour

Power :0.75KW

Desalination rate :>99.5%

Power supply: AC24V-220V / 50Hz /60HZ

Salinity of produced water: <700mg/L

Protection grade of electric control :IP54

System recovery rate :25% (depending on temperature and water quality)

Dimension: 800*400*300 (L*W*H)

Operating pressure :<6.5Mpa

Net weight: 50Kg

Reverse osmosis membrane: RO membrane shell

Material composition :SUS316 stainless steel

System function

1. high pressure unloading, when the high pressure pump water pressure exceeds 6.2MPa, the equipment automatically shutdown protection action and sound and light alarm.

2. low-pressure shutdown protection, when the pretreatment water supply is insufficient to cause the high-pressure pump inlet pressure is less than 0.05MPa, it will automatically shut down to protect the action and issue sound and light alarms.

3. configured with a manual multi-way valve, multi-media filter cleaning when the differential pressure reaches 0.1MPa. 4.

4. reverse osmosis membrane cleaning system can be configured to physically clean, chemically clean and refill the reverse osmosis membrane components with protective fluid.

Main accessories Inlet pump: SUS316

Multi-media filter: Ø100FRP

Security filter: 10’ x 10μm, UPVC

Precision filter: 10’ x 5μm, UPVC

High pressure pump: Italy imported AR brand / South pump (CNP)

Reverse osmosis membrane: LG / U.S. Dow / Toray / Hydrogen seawater membrane

Membrane shell: Chengda sea (FirstLine) FRP material

Cleaning tank: PE

Chemical cleaning device: system supporting

Electrical components: Schneider brand

Conductivity meter: Kreda brand

Factory equipment list

1. water treatment equipment

2. product operating instructions, use of video* operation

3. Completion information (product certification, factory test report, packaging list)

4. Other consumables accessories

* 1. water production refers to the water temperature of 25 ℃, salt content of 35000mg / L, operating pressure of 5Mpa under the conditions of water production.

2. The equipment can be customised according to customers' requirements.
