Island Underground Saltwater Desalination System

Power-Generating Island Water Generator

Product Model: JC-15T/D

The quality of the desalinated water produced meets the national drinking water quality standard GB5749-2022

Water Production Rate: 625 litres per hour
Power Consumption: 5 kilowatts
Seawater Desalination Efficiency: >99.5%
Power Supply: AC 220V-380V / 50Hz / Single-phase and three-phase customizable
Product Water Conductivity: <700 milligrams per litre
Electrical Control Protection Rating: IP54
System recovery rate: 10-30% (depending on temperature and water quality)
Dimensions: 1300 x 800 x 1750 millimetres
Operating pressure: <6.5 MPa
Net weight: 480 kilograms
Reverse osmosis membranes and membrane housings: 4 pieces x 4 pieces
Material composition: SUS316 stainless steel System functions

1. High-pressure unloading: When the high-pressure pump water pressure exceeds 6.2 MPa, the equipment will automatically shut down for protection and issue an audible and visual alarm.

2. Low-pressure shutdown protection: When the pre-treatment water supply is insufficient, causing the high-pressure pump inlet pressure to drop below 0.05 MPa, the equipment will automatically shut down for protection and emit an audible and visual alarm.

3. The reverse osmosis membrane cleaning system can be configured for physical cleaning, chemical cleaning, and rinsing of reverse osmosis membrane components with protective fluid.
Main components Inlet pump: SUS316
Safety filter: 20' x 5μm,
UPVC fine filter: 20' x 5μm, UPVC
High-pressure pump: Italian-imported AR brand
Reverse osmosis membrane: LG / TS /
Hydrogen membrane housing: (first line) FRP material
Cleaning tank: 20L
Chemical cleaning device: System-matched
Electrical components: Schneider brand or equivalent.
Conductivity meter: Kreida. Factory Equipment List

1. Water treatment equipment

2. Product user manual, usage video*

3. Completion documents (product conformity certificate, factory test report, packing list)

4. Other consumables and accessories

The following is information about the seawater desalination unit:
1. Daily water production: The unit can produce 15 tonnes of freshwater daily, equivalent to 15,000 litres, sufficient to meet the freshwater needs of small rural communities, small guesthouses, hotels, ships, factories, and construction sites.
2. Energy consumption: The unit has a power rating of 5,000 watts and operates relatively efficiently, which is a significant advantage for users operating in environments with limited energy resources.
3. Power compatibility: The device supports a power input of 380-440 volts, offering flexibility and the ability to operate in various power environments.
4. Physical dimensions: The device measures 1,300 millimetres in length, 800 millimetres in width, and 1,750 millimetres in height, making it a compact unit that is easy to move and suitable for installation in confined spaces.
5. Application Scenarios: This device is particularly suitable for environments requiring portable freshwater solutions, such as ships, coastal areas, household water use, offshore platforms, remote islands, emergency rescue, or disaster response.
6. Technical Features: Although you did not provide specific technical details, such devices typically use reverse osmosis (RO) technology, which separates salts and other impurities by forcing water molecules through a semi-permeable membrane under pressure.
7. Convenience: The portable design enables rapid deployment, which is particularly practical in emergency situations or mobile work environments requiring quick response. For further analysis or other questions, such as equipment maintenance, cost-benefit analysis, or market comparisons, please contact us for discussion.

Overview:
In today's world of increasingly scarce water resources, Dongguan Jingchuang Environmental Protection Equipment Co., Ltd. is dedicated to transforming the vast oceans into a source of life, providing clean and safe drinking water to the global community.

Seawater Desalination Equipment Ship Island Filtration Drinking Water Purifier Subsea Water Filtration System

Commercial Seawater RO Membrane Filtration Water Treatment Plant for removing salts and purifying water quality. The system includes a booster pump, FRP/carbon steel pre-treatment tanks (sand filters, activated carbon filters), filter cartridge housing, chemical dosing system, high-pressure pump, FRP membrane pressure vessel, 2540 or 4040 membranes, control panel, and touchscreen control system.
Materials and component brands can be adjusted based on raw water quality and customer requirements.

Note: Due to the special nature of the product, professional consultation is required before purchase. Please contact customer service, and we will recommend suitable products based on your water usage needs and water quality issues. To avoid unnecessary complications in the future, please do not purchase equipment blindly. If you require specific technical specifications, parameters, or images for professional troubleshooting, please contact customer service. We will address your professional inquiries. Thank you for supporting Jingchuang Environmental Protection Experts. Thank you!
